Klein Tools MM320 - Electrical Specifications; DC Current Measurement

3
ELECTRICAL SPECIFICATIONS
Function Range Resolution Accuracy
DC Voltage
(V DC)
200.0mV 0.1mV ± (0.7% + 5 digits)
2000mV 1mV
±(0.5% + 5 digits)
20.00V 0.01V
200.0V 0.1V
±(0.8% + 5 digits)
600V 1V
AC Voltage
(V AC)
200.0V 0.1V
±(1.2% + 10 digits)
50 to 60Hz
600V 1V
DC Current
(A DC)
200.0μA 0.1μA
±(1.0% + 5 digits)20.00mA 10μA
200.0mA 100μA
10.00A 10mA ±(2.0% + 5 digits)
Resistance
200.0Ω 0.1Ω ±(1.0% + 5 digits)
2000Ω 1Ω
±(0.8% + 5 digits)20.00kΩ 0.01kΩ
200.0kΩ 0.1kΩ
2000kΩ 1kΩ ±(1.2% + 5 digits)
Battery Test
9V 10mV
±(0.5% + 5 digits)
1.5V 1mV
• Diode Test: Approx. 0.6mA, open circuit voltage 2.0V DC
• Continuity Check: Audible signal <100Ω
• Battery Test: 9V (approx. 20mA, 450Ω load);
1.5V (approx. 15mA, 100Ω load)
• Sampling Frequency: 2 samples per second
• Overload: "OL" indicated on display, overload protection
600V RMS in all settings
• Polarity: "-" on display indicates negative polarity
• Display: 3 ½ digit, 2000 Count LCD
