DIVA SLIM PELLET BOILER STOVE
13
- It is forbidden to allow other air intake conduits and system pipes to transit inside the flue gas pipes, even if they are
over-sized.
FURTHER SPECIFICATIONS TO BE CONSIDERED
- The appliance works with the combustion chamber in depression and the flue pipe in pressure; it is essential that
the flue gas outlet is hermetically sealed.
- The flue pipes inside the installation room must be made of a suitable material (see current regulations) and
equipped with seal gaskets with a minimum diameter of 100 mm.
- The pipes must have a double wall (thermally insulated) or be suitably insulated with rock wool. The
maximum temperature of the flue pipe inside the room must not exceed 70°C.
- IT IS MANDATORY TO HAVE AN INITIAL VERTICAL SECTION OF AT LEAST 0.5 M IN ORDER TO
GUARANTEE CORRECT FLUE GAS DISCHARGE.
- Every direction change must be carried out with a T-shaped fitting and inspection cap. The tubes must be smoketight
thanks to special seals capable of withstanding temperatures of up to 250°C. Attach the pipes to the wall with special
collars to prevent any vibration.
- IT IS STRICTLY FORBIDDEN TO INSTALL DRAUGHT REGULATION VALVES (BUTTERFLY VALVES). WALL
If the flue is old or too large (internal diameter greater than 15 cm), it must be ducted using a stainless steel pipe that is
suitably insulated (with rock wool or vermiculite) and sized according to the route. The connection to the flue must be
appropriately sealed.
When assembling the flue, there must be no more than 4 direction changes.
Chimney
The chimney is a device crowning the flue, used to ease dispersion of combustion products.
