klover DIVA SLIM - Annual Cleaning

DIVA SLIM PELLET BOILER STOVE
32
EN - Rev. 1.0
To ensure correct operation, it is necessary to remove the sawdust deposited on the base of the tank (Figure 9) at least
once every 30 days. The pellet tank must be emptied at the end of every season.
Annual cleaning
The annual cleaning of the appliance must be done at least once a year so as to always guarantee efficient performance
and optimal operation. To complete these operations, we recommend contacting the Authorised Technical
Assistance Centre, which will proceed as explained below:
Perform routine and extraordinary cleaning;
Remove the upper grille (Figure 10).
Pull the probe out of the upper cover (Figure 11) and unscrew the eight hex head screws to remove the latter (Figure 12).
11
12
9
10
