DIVA SLIM PELLET BOILER STOVE
22
Menu 04 – Choose language
Allows you to select the dialogue language from the available choices (Italian, English, French, German and Spanish).
Menu 05 – Acoustic alarm
Allows you to enable or disable the acoustic signal in the event of an alarm. The alarm signal is only available on the
appliance board, and not on the external “Remote control”.
Menu 06 – Initial load
Enables pellet pre-loading for 180” when the appliance is switched off and cooled down. Start the function with button 1
and stop with button 4. This may be useful if the appliance is switched on after the tank has been completely emptied, or
when it is filled for the first time. Warning: once the operation has been completed, before switching on the
appliance you should empty the accumulation of pellets deposited inside the brazier.
Menu 07 – Fireplace status
It allows for viewing the instantaneous state of the appliance, by showing the state of the various devices connected to it.
Several pages are displayed in succession. The data is reserved for Technical assistance Centre.
Menu 08 – Technical calibration
Allows you to access all data reserved for the Technical Assistance Centre. Access is protected by a password.
Unauthorised access can cause serious damage to the equipment, to things and the environment as well as personal
injuries.
Menu 09 – System type
Allows you to configure the appliance according to the type of system is has been connected to (see “System
configuration”).
INITIAL START-UP
System configuration
Before commissioning the appliance it is advisable to choose which type of system it has been connected to, by
accessing “Menu 06 – System type”.
The available configurations are given here below:
PLUMBING LAYOUT “1” – Boiler stove connected to a heating system and (potentially) an external plate heat
exchanger for the production of DHW.
