Diaphragm Pumps N 143/186.12 Spare parts and accessories
Translation of original Operating and Installation Instructions, english, KNF 121610-121613 07/16 27
10. Spare parts and accessories
Spare Parts
N 143 AN.12 E N 143 SN.12 E
N 186.1.2 AN.12 E N 186.1.2 SN.12 E
N 186.3 AN.12 E N 186.3 SN.12 E
Spare part
Position*
Order No.
Working diaphragm
(L)
001620
Safety diaphragm
(S)
001622
Valve plate
(G)
001615
O-ring
(F, H, P)
002445
O-ring
(R)
002433
O-ring
(T)
002431
Tab. 18 *according to Fig. 9
N 143 AV.12 E N 143 SV.12 E
N 186.1.2 AV.12 E N 186.1.2 AV.12 E
N 186.3 AV.12 E N 186.3 AV.12 E
Spare part
Position*
Order No.
Working diaphragm
(L)
001904
Safety diaphragm
(S)
001906
Valve plate
(G)
001908
O-ring
(F, H, P)
002460
O-ring
(R)
002450
O-ring
(T)
002448
Tab. 19 * according to Fig. 9
Accessories
Accessories
Order No.
Wrench for retainer plate
018816
Tab. 20
