Solution Blending Devices and Alarms
Water flow detection
The large flow meter connected to the water solenoid valve
senses water flow and sends back signals to the main controller
that water is flowing at the calibrated rate of flow. Anytime water
flow drops below the calibration setting a flow alarm message
will occur and the system will stop production of the current for-
mula.
Low level sensor
Chemical levels in the supply container are monitored by a float
type level sensor. The level sensor should be positioned at the
bottom of the chemical container along with the chemical suction
tube. When the level float sinks to the bottom of its travel an
alarm will sound, low detergent error recorded and display mes-
sage “detergent low” message shown until the container is re-
placed.
Temperature sensor precision/type
The RTD type temperature sensor will monitor water tempera-
ture to the specified range programmed into the system. With the
temperature monitoring feature on an error will be recorded and
alarm displayed if the system fails to reach the minimum temper-
ature
CHECK WATER
SUPPLY
DETERGENT LOW!
PRESS START TO
RUN WATER UNTIL
TEMP IS IN RANGE.
TEMP (C) 022
PRESS START TO
RUN WATER UNTIL
TEMP IS IN RANGE.
TEMP (C) 022
