Hot/Cold Water Mixing Valve
To provide tempered water to the sink or receptacle a water tempering valve can be used.
Follow all local plumbing and safety codes when installing these devices. See page 8 for
recommended configuration and installation.
How it works
Select from one of four batch volumes and solution concentrations, then press the START
button to automatically fill instruments sinks or soaking tubs with the precise ratio of
concentrated chemical and water. Optional soak time function counts down the time for the
medical devices to be submerged in the cleaning solution. An audible tone alerts the technician
when soak time has been reached. Usage data can be downloaded from the system via USB
drive or viewed on the display.
The Flexible hose model should be used where filling of sinks or tubs are not directly beneath
where the system will be mounted. The 8-ft (2.4 M) flexible hose can be placed inside the sink
or tub and held in place with a hose adaptor or vinyl suction cup.
Volume Selection Screen Flexible Hose Model Rigid Spout Model
