1 General Information
The four indent crimping tool is a pair of handheld pliers, which is manufactured by using the latest technology
and the general accepted safety regulations. The pliers may only be used in proper working condition. The
four indent crimping tool is used to crimp male and female turned contacts and should be used solely for the
purpose , for which it is intended for as described in this manual.
Crimp Area with
Indenters
Limit Stop
Adjustment Wheel for
Precision Settings
LocatorSet Screw with crimp locking device
Metric Scale with
0.2 mm increments
for a preliminary
adjustment
Any unauthorized use or usage not according to the intended purpose is regarded as improper and may
cause damage to the tool. Rennsteig will not assume responsibility for such damages.
Art. No. Finish Profile Capacity
mm
2
AWG
Length
mm
Weight
g
97 52 63
Tool with standard indents in plastic case
(with locator)
0,08–2,5 28–13 175 820
97 52 65 0,14–6,0 26–10 230 1190
97 52 65 A
Tool with standard indents in plastic case
(without locator)
0,14–6,0 26–10 230 1190
