10
ASSEMBLY INSTRUCTIONS
4. To Attach/Remove Battery Pack
To Attach Battery Pack
a. Make sure that the switch is in the OFF
position.
b. Align the mounting grooves on the battery
pack with the raised ribs in the trimmer’s
battery port, as shown.
c. Slide the battery pack into the trimmer until it
snaps into position.
NOTICE: Make sure that the latch on the trimmer
snaps into place and the battery pack is secured to
the trimmer before beginning operation.
To Remove Battery Pack
WARNING
• Always be aware of the location of your feet, children, or pets when pressing the
battery-release button.
• Serious injury could result if the battery pack falls. NEVER remove the battery pack at a
high position.
a. Hold the battery pack in the palm of your hand.
b. Press the battery-release button with your thumb. The battery pack will disengage from the
latch.
c. Grasp the battery pack and remove it from the trimmer.
WARNING
• Battery tools are always in operating condition. Therefore, the trigger switch should always be
in the OFF position when the tool is not in use or when carrying the tool at your side.
4
Battery-release
Button
