11
OPERATING INSTRUCTIONS
2. Trigger Switch
a. To turn the saw ON, press the lock-off button
(B), then squeeze the trigger switch (D).
WARNING
• The blade should reach full speed before it
comes into contact with the workpiece.
b. To turn the saw OFF, release the trigger switch
and allow the blade to come to a complete
stop.
Electric Brake
The circular saw is equipped with an electric brake.
When the trigger switch is released, the electric
brake engages automatically to quickly stop the rotation.
3. Blade Guard System
The lower blade guard (H) on the circular saw is
there for the operator’s protection and safety. Do
not alter it for any reason.
If the lower blade guard becomes damaged or if the
blade begins to run slowly or sluggishly, DO NOT
operate the saw until the damaged part has been
repaired or replaced. ALWAYS leave the guard in its
correct operating position when using the saw.
DANGER
• When sawing through a workpiece, the lower
blade guard does not cover the blade on the
underside of the workpiece. ALWAYS keep hands and body away from the cutting area.
Serious injury will result if any part of the body comes into contact with the moving blade.
WARNING
• To avoid possible serious injury, never use the saw when the lower blade guard is not
operating correctly. Check the lower blade guard for correct operation before each use. It
should move freely and instantly return to the closed position. If the saw is dropped, check
the lower blade guard and bumper for damage at all depth settings before using it.
If the lower blade guard does not snap closed at any time, take it to a qualied service
technician for repair.
3
H
2
B
D
