25
OPERATING INSTRUCTIONS
kobalttools.com
TO MAKE AN L-CUT
L-cuts are cuts that remove a piece of tile to t in a
corner, around a cabinet, or a piece of moulding and are
made by making two separate cuts.
Note: Only overcut on the bottom or underneath side of
the material being cut.
• Using a marker or grease pencil, mark the area to
be cut on material.
• Remove the miter gauge.
• Position the rip guide rail (D) the desired distance from
the wheel for the cut and securely lock the lever.
• Place the material on the table, rmly against the
rip guide.
• Make sure the material is clear of the cutting wheel
before turning on the saw.
• Turn the on/off switch to the ON position.
• Let the cutting wheel build up to full speed and wait
for the wheel to get wet before moving the material
into the wheel.
• Hold the material rmly against the rip guide and feed
the material into the cutting wheel.
• Make the cut far enough into the material without
over-cutting.
• When the cut is made, turn the saw OFF. Wait for
the cutting wheel to come to a complete stop before
removing any part of the material.
• Turn the material, adjust the rip guide, and make the
second cut along one of the marks. This time overcut
the other line and the cut piece should separate from
the rest of the material.
• When the second cut is made, turn the saw OFF.
Wait for the cutting wheel to come to a complete stop
before removing any part of the material.
D
D
