KOBE SQB-650-5A Series User Manual (English)

Questions and Answers:

W
William JonesJul 28, 2025
Why are the motors and lights not working on my KOBE SQB-650-5A Ventilation Hood after installation?
- S
  Suzanne FosterJul 28, 2025
  If, after installation, the motors and lights on your KOBE Ventilation Hood aren't working, there are several potential causes: * **Power Supply:** Ensure that the circuit breaker and the unit's power switch are turned ON. Use a voltage meter to verify the power supply. * **Wiring:** Check and tighten all wire connections to ensure they are secure. * **Control Unit/Processor Board:** Verify the wire continuity from the control unit to the processor board. A disconnection here could be the issue.
R
Robin SkinnerAug 2, 2025
Why is my KOBE SQB-650-5A Ventilation Hood not venting out correctly?
- C
  crystal17Aug 2, 2025
  If your KOBE Ventilation Hood isn't venting correctly, consider these factors: * **Defective Components:** The control unit or processor board might be defective and require replacement. * **Installation Clearance:** Make sure the range hood is installed within the recommended clearance (26"-30" for standard hoods, 30"-36" for island hoods). * **Airflow:** Ensure sufficient make-up air by opening a window to enhance performance. * **Obstructions:** Check for and remove any obstacles blocking the duct work.
G
Guy FoxAug 7, 2025
What to do if lights are working, but motor(s) is not on KOBE SQB-650-5A Ventilation Hood?
- J
  jaredfryAug 7, 2025
  If the lights are working but the motor(s) isn't on your KOBE Ventilation Hood, consider these potential issues: * **Defective Control Unit or Processor Board:** The control unit or processor board may be defective and need replacement. * **Defective Motor(s):** The motor(s) themselves could be defective and require replacement. * **Defective Capacitor(s):** The capacitor(s) might be defective and need replacement.
J
Jacob TaylorAug 12, 2025
What to do if the motor is working, but the lights are not working on my KOBE Ventilation Hood?
- L
  Lori SilvaAug 12, 2025
  If the motor is working, but the lights aren't on your KOBE Ventilation Hood, here's what to check: * **Installation:** Ensure the hood is securely installed by tightening the mounting bracket. * **LED Light Fixtures:** The LED light fixture(s) might be defective and need replacement. * **Wiring:** Check the wire continuity from the processor board to the light transformer and then to the LED light fixture(s).
D
Daniel HallAug 17, 2025
Why is my KOBE Ventilation Hood vibrating?
- J
  Jennifer JohnsonAug 17, 2025
  If your KOBE Ventilation Hood is vibrating, here are some possible reasons: * **Defective Control Unit/Processor Board:** The control unit or processing board could be defective and require replacement. * **Loose Blower System:** Make sure to tighten the turbine impeller/squirrel cage and air chamber. * **Imbalanced Impeller:** The turbine impeller/squirrel cage might be unbalanced and need replacement.
H
Harold SinghAug 22, 2025
Why is cold air coming into the home from my KOBE Ventilation Hood?
- E
  Eduardo HerreraAug 22, 2025
  If cold air is entering your home through the KOBE Ventilation Hood, consider the following: * **Pipe Size:** The ducting might be smaller than the recommended size; change it according to the manufacturer's suggestion. * **Pipe Connection:** Ensure the pipe connection is properly sealed. * **Damper:** Check the damper installation to ensure it's properly installed or not missing.
