How to Set OSD MENU SET UP Functions
29
■󰼿 COLOR (Electronic Day & Night)
◎󰼿 AUTO : Automatically discern day or night settings and switches to the appropriate mode for the surrounding conditions.
While mode is switched to COLOR during the day, it is switched to B/W at night.
◎󰼿 ON : Mode isn't automatically switched and fixed at COLOR.
■󰼿 SYNC : In the area of 60Hz(50Hz), a user can put output phases of several units in tune using Line Lock
function without a synchronizing signal generator.
SYNC
▶PHASE󰼿󰼿󰼿󰼿󰼿󰼿󰼿l󰼿-󰼿-󰼿-󰼿-󰼿-󰼿I󰼿225󰼿
[Notes] If AFC is set as OFF, COLOR function are not available.
󰼿󰼿󰼿󰼿󰼿󰼿󰼿󰼿󰼿󰼿󰼿※󰼿 Camera is more liable to be out of focus under an infrared lighting than general ones.
INT : Internal Synchronization Method.
LL : Line Lock Method (AC 24V).
Press SET UP button.
A user can select a desired phase among 0 to 359.
[Note]
In a product using DC 12V, SYNC is fixed at "INT" mode.
30
■󰼿 MOTION DETECTION
MOTION󰼿DETECTION
Press󰼿SET󰼿to󰼿Return
AREA󰼿1▶AREA󰼿SEL󰼿
AREA󰼿STATE󰼿 ON
I-󰼿-󰼿I󰼿-󰼿-󰼿I󰼿10
I-󰼿I󰼿-󰼿-󰼿-󰼿I󰼿25
I-󰼿-󰼿I󰼿-󰼿-󰼿I󰼿20
I-󰼿-󰼿I󰼿-󰼿-󰼿I󰼿40
TOP󰼿
DOWN
LIGHT
RIGHT
- This product can detect motions of subject in the 4 areas on screen. During the motion detection,
a message "MOTION DETECTION" is displayed, which enables a person to do his job effectively.
The motions of subject are detected by the differences in its
contour, brightness, and color.
(1) Press SET UP button
- OFF : deselects the function.
- ON : detects a MOTION occurred in a selected area.
(2) In AREA SEL, select one among 4 areas where a user does
motion detection.
(3) Change the state of a selected area to ON.
(4) Using UP, DOWN or LEFT, RIGHT button,
adjust the size of detection area.
(5) Press SET UP button to save the changed value and finish.
