Kodak 104 - Mechanical Components List (100-123)

14
Spare Parts
* available in Spare Parts Kit - Small, Part No. 1F7975
n/a - not available
Pos. Part No. Description
Standard Processor
- 1F7972 Roller rack, developer
- 1F7973 Roller rack, fixer
- 1F7974 Roller rack, wash & dryer
100 n/a Side plate dev. w. shafts (left)
n/a Side plate dev. (right)
n/a Side plate fix. w. shafts (left)
n/a Side plate fix. (right)
102 1F7967 Guide bar straight, short
103 1F7968 Guide bar with nose
104 1F7969 Guide bar, curved
105 * Flat spring 55
106 * Screw M4x10, A4
107 * Hexagon nut M4, A4
108 1F7970 PU-roller 35 ground
109 n/a Drive shaft rack
110 * Gear t = 16, D-hole
111 * Gear t = 32, round hole
112 * Gear t = 32, D-hole
113 * Worm wheel
114 * Bearing
115 n/a Bearing, large
116 n/a Black circlip
117 n/a Dryer side plate left w. shafts
n/a Dryer side plate right
119 1F7971 Rubber roller 35
120 n/a Air jet (35)
121 n/a Dryer plate, large
122 n/a Dryer plate, small
123 * Flat spring 35
