SERVICE MANUAL
16 18NOV97 – SM5440-1
A091_0010HA
A091_0010HCA
SELECT LEVER
SPRING
SELECT LEVER
TAB
LIFT
LEVER
BEARING
NUT
E-RING
E-RING
BEARING
ASSEMBLY
CAM STACK
LIFT LEVER SHAFT
