The LOWER HOUSING ASSEMBLY is a part of the cooling function. To operate the projector with the LOWER
HOUSING removed, make a FAN COVER TOOL.
Tool Description
TL-1744 AUTO-FOCUS GAUGE
TL-2264 FOCUS TEST (flat field)
TL-3002 AUTO-FOCUS TARGET SLIDE
TL-3003 ADJUSTMENT T-BAR
TL-3005 ADJUSTMENT TOOL
TL-3255 Torx DRIVER SET
TL-4276 SUPER LUBE
DIGITAL MULTIMETER
11.5 cm
(4.5 in.)
A091_0024GA
TOOL
A091_0024GCA
COVER
FAN
Cut here.
