5 Position the beam indicated device as close as possible to the patient.
6 Activate the sensor.
The sensor activation can be done by :
The RVG icon will turn into green
You can also orientate the image before acquisition.
By default, the image displays vertically as if an image
of a tooth from the lower dental arch was acquired.
You now have 90 seconds to take the X-ray image.
7
Trigger the X-ray emission.
The image will automatically be displayed on your computer screen.
6
a- either
clicking on
the RVG
icon on the
software
toolbar
b- or
pressing
on F2 on
the keyboard
c- or
using the button
on the sensor
remote
control.
