22
Fix connector on
PCB(X11, X12)
Antenna
Stern side
Shield cover
Cable shield
Radome (bottom)
Fixing plate
Rubber ring
Interconnecting cable
X12 (Connect here)
Radome (bottom)
PCB
Inner shield
X11 (Connect here)
Fig.3-8-2 Fitting interconnecting cable (RA41C)
