21
A
ntenna
Stern side
Shield cover
Cable shield
Radome (bottom)
Fixing plate
Rubber ring
Interconnecting cable
Fix connector on
PCB(X1)
X1 (Connect here)
Radome (bottom)
PCB
Inner shield
Fig.3-8-1 Fitting interconnecting cable (RA40C)
