5
PTO, with Slip Clutch 113-72SC 1
5 PTO, with Slip Clutch 113-84H 1
6 1/2” Lock Nut 115 SMH 1 1 1 1 1 1
7 1/2” x 3” Grade 2 Bolt w/nut 200 SBLT 1 1 1 1 1 1
8 1/8” Cotter Pin 117 SMH 1 1 1 1 1 1 1 1
9 1” Fine Thread Nut 118 SMH 1 1 1 1 1 1 1 1
10 1” Washer - Flat 119 SMH 1 1 1 1 1 1 1 1
11 Spun Metal Dish Blade Carrier 120 S 1 1 1 1
11 1/2”x16 1/2” Flat Blade Carrier 121 MH 1 1 1
11 5/8”>x27 1/2” Flat Blade Carrier (Oblong) 122 H 1
12-13 1 1/8” Blade Bolt Kit 124 SMH 2 2 2 2 2 2 2 2
14 Mower Blade
Total Length 15” K-215 2
14 Mower Blade
Total Length 18 1/2” K-213 2
14 Mower Blade
Total Length 24 1/2” K-214 2 2
14 Mower Blade
Total Length 30 1/4” K-212 2 2
Ref. No. Description Part No. ST-40 ST-48 ST-60 ST-72 MD-60 MD-72 HD-72 HD-84
RB-60 RB-72 RB-SHD-72SC* RB-SHD-84SC*
10/11
15
Kodiak Rotary Cutters - 3 Point Hitch
* See Page 21 for Gearbox Requirements
14 HD Mower Blade 1/2”x4”x30 3/4” K-210 2 2
15 1/2” x 4 1/2” Bolt 2 2 2 2 2 2 4 4
16 1/2” Nut, Self Locking 126 SMH 2 2 2 2 2 2 4 4
17 Tail Wheel (No TAT) 127 SMH 1 1 1 1 1 1 2 2
18 1/2” Lock Nuts 2 2 2 2 2 2 4 4
19 Replaceable Skid Shoes SS60-72 2 2 2 2 2
19A Replaceable Skid Shoes SS84 2
20 1/2” Nut, Lock Washer 130 SMH 4 4 4 4 4 4 8 8
21 1/2” x 1 1/2” Bolt 131 SMH 4 4 4 4 4 4 8 8
22 Tail Wheel Hub, Cast 132 SM 1 1 1 1 1 1
22A Sealed Bearing Hub 133 H 2 2
23 Tail Wheel Bracket 134 SMH 1 1 1 1 1 1
23A Tail Wheel Bracket 134 H 2 2
24 1/2” x 1 1/2” Bolt 135 SMH 1 1 1 1 1 1 2 2
25 1 1/8” Flat Washer 136 SMH 1 1 1 1 1 1 2 2
26 Tail Wheel Tube 137 SMH 1 1 1 1 1 1
26A Tail Wheel Tube 137 H 2 2
27 3/4” x 7 1/2” Axle Bolt w/ Nut 128 SM 1 1 1 1 1 1
28 1” x 8” Axle Bolt w/ Nut 128 H 2 2
31 Back Braces 142 SM 2 2 2 2 2 2
31A Back Braces 143 H 2 2
32 1/2” x 4” A-Frame 144 SM 2 2 2 2 2 2
32 5/8” x 4” A-Frame 145 H 2 2
33 1/2” x 3” Capscrew, Lock Nut 146 SMH 1 1 1 1 1 1 1 1
34 1/2” x 2 1/2” Capscrew, – 147 SMH 1 1 1 1 1 1 1 1
34A Stop Bushing S B 1 1 1 1 1 1 1 1
35 7/8” Nut, Lock, Fine Thread 148 SM 2 2 2 2 2 2
35 3/4” S-Lock Nut 149 H 2 2
36 Lift Pin Bushing L P B 2 2 2 2 2 2 2 2
36A Lift Pin Cat. #1 151 SM 2 2 2 2 2 2
36A Lift Pin Cat. #2 708 2 2
37 Main Body 152 SMH 1 1 1 1 1 1 1 1
38 Pivot Arm 153 H 1 1
38A Pivot Bushing P B 1 1 1 1 1 1 1 1
39 Gearbox Shield Shear Pin GS - SM 1 1 1 1 1 1
39A Gearbox Shield Slip Clutch GS - MD 1
39B Gearbox Shield 7’ Cutter GS - LG 1
** Metal gearbox shields are optional and available for all size cutters.
