Gearbox
Assembly
Model GB-40
40 HP - 1:1.47 Ratio
18
04/12
Key No. Description Part No. Size
101 Input Seal 60002 60060 34.93 - 54.13 - 11.12
Smooth Black Gearbox 60060-C 35 - 54 - 9
102 Face Plate 20002
103 Ball Bearing 207K 50006
104 Retaining Ring 200000
105 Input Shaft 40040
106 Input Gear 22T 30003
107 Retaining Ring 200000
108 Shim .004
109 Ball Bearing 208K 50007
110 Housing 10001
111 Pressure Relief Plug 140033
112 Gasket 70002
113 Output Shaft w/ Gear 15T 30002
114
Ball Bearing 208K 50007
115
Retaining Ring 200001
116 Spacer 210013
117 Ball Bearing 208K 50007
118 Output Seal 60003 60061
39.67 - 54.13 - 9.53
Smooth Black Gearbox
60061-C 39.7 - 54 - 11
119 Bottom Cap 20003
40 HP Gearbox
