Kodiak 40” - Page 17

Ref. No. Description Part No. PT-48 PT-60 PT-72 PT-60 MD PT-72 MD PT-72 HD PT-84 HD
6 3/4” x 2 1/4” Nut 606 2 2 2 2 2 2 2
7 5/8” U Bolt, Nuts 607 2 2 2 2 2 2 2
8 1/8” Cotter Pin 117 SMH 1 1 1 1 1 1 1
9 1” Fine Thread Nut 118 SMH 1 1 1 1 1 1 1
10 1” Washer - Flat 119 SMH 1 1 1 1 1 1 1
11 Metal Dish Blade Carrier 120 ST 1 1 1
11 1/2”x16 1/2” Flat Blade Carrier 121 MH 1 1 1
11 5/8”>x27 1/2” Flat Blade Carrier (Oblong) 122 H 1
12 (see #13) 2 2 2 2 2 2 2
13 1 1/8” Blade Bolt 124 SMH 2 2 2 2 2 2 2
14 Mower Blade
Total Length 15” K-215 2
14 Mower Blade
Total Length 18 1/2” K-213 2
14 Mower Blade
Total Length 24 1/2” K-214 2 2
14 Mower Blade
Total Length 30 3/4” K-212 2 2
Kodiak Rotary Cutters - Pull Type
10/11
17
14 HD Mower Blade 1/2”x4”x31 1/4” K-210 2
15 3/4” x 6” Bolt 125 SMH 2 2 2 2 2
15A 3/4” x 6 1/2” Bolt 2 2
16 3/4” Nut, Self Locking 126 SMH 2 2 2 2 2 2 2
17 Tail Wheel 127 SMH 1 1 1 1 1 1 1
18 3/4” x 7 1/2” Bolt and Nut 128 SMH 1 1 1 1 1
19 1” x 8” Bolt and Nut 128 H 2 2
20 1/2” Nut, Lock Washer 130 SMH 4 4 4 4 4 4 4
21 1/2” x 1 1/2” Bolt 131 SMH 8 8 8 8 8
22 Tail Wheel Hub, Cast 132 SM 1 1 1 1 1 1
22A Sealed Bearing Hub 133 H 2
23 Replaceable Skid Shoes 2 2 2 2 2 2
26 Tail Wheel Frame N/A 1 1 1 1 1 1 1
27 Adjustment Bar 601 1 1 1 1 1 1 1
28 5/8” x 2 1/4” Nut - Top 602 1 1 1 1 1 1 1
28 1/2” x 2” Nut - Bottom 603 2 2 2 2 2 2 2
29 Third Link 604 1 1 1 1 1 1 1
30 Ratchet Jack 709 1 1 1 1 1 1
31 Tongue 605 1 1 1 1 1 1 1
36 Body N/A 1 1 1 1 1 1 1
37 1/2”x 3” Gr.2 Shearbolt w/nut 200 SBLT 1 1 1 1 1
38 Gearbox Shield Shear Pin GS - SM 1 1 1 1 1
38A Gearbox Shield Slip Clutch GS - MD 1
38B Gearbox Shield 7’ Cutter GS - LG 1
** Metal gearbox shields are optional and available for all size cutters.
