HD - PTO SHAFT
10/11
23
***NOTE: SHIELDS ARE FOR UP TO 910MM AND 1210MM X-X DRIVE LINES...CUT TUBES TO FIT
ASSEMBLE THE SHIELDS ON EACH HALF, THEN CUT THE TUBES THE SAME LENGTH AS THE
SLIP TUBES. MAKE SURE THEY DO NOT COME TOGETHER AND BIND WHEN THE 2 HALVES
ARE ASSEMBLED.
ALWAYS KEEP SHIELDING IN PROPER WORKING ORDER, USE PROPER LENGTH CONES, AND
MAKE CERTAIN ALL SHIELDING FURNISHED WITH EQUIPMENT OR DRIVE LINE IS IN PLACE
AND THAT THE CROSSES AND YOKES ARE COMPLETELY COVERED BY EITHER THE INSTALLED
SHIELD OR EQUIPMENT. IT IS THE USER’S RESPONSIBILITY TO USE CORRECT SHIELDING.
Please call Kodiak Parts Dept.
at 423-336-2390 BEFORE
ordering PTO parts.
Series 5 - 6 - 7
Key No. Description Series Part No.
1 Outer Tube Bearing 5 K5101
1 Outer Tube Bearing 6 K6101
2 Stiffner Bar 5-6 K5102
3 Standard Cone 5-6 K5103
4 Stop Snag Ring 5-6 K5104
5 Safety Sleeve 5-6 K5105
6 Outer Tube
910mm, 26” w/decal 5-6 K5106
6 Outer Tube
1210mm, 38” w/decal 5-6 K5107
7 Inner Tube 910mm, 26” 5-6 K5108
7 Inner Tube 1210mm, 38” 5-6 K5109
8 Inner Tube Bearing 5 K5110
8 Inner Tube Bearing 6 K6110
9 Long Cone 5-6 K5111
10 Short Cone 5-6 K5112
11 Danger Decal 5-6 K5113
12 Chain 5-6 K5114
