Kodiak G03 series - REAR PANEL COMPONENTS; Main Rear Panel Layout; Connector Details

Kodiak Recirculating Chiller Technical Manual
Manual # 820-0109, Rev. Y, 07/08/10 - 13 - Check Lytron’s website www.Lytron.com
for the most current technical information.
REAR PANEL COMPONENTS
(Reference Spare Parts List in this manual)
POWER
ENTRY
FLUID OUT
OF CHILLER
CIRCUIT
BREAKER
REMOTE START &
CUSTOMER CONTACTS
RS232
FLUID IN
TO CHILLER
NOTCH
INDICATES
PIN 1
1- -
4
2- -
5
