Kodiak G03 series - FRONT VIEW; Front Panel Component Identification

Kodiak Recirculating Chiller Technical Manual
Manual # 820-0109, Rev. Y, 07/08/10 - 33 - Check Lytron’s website www.Lytron.com
for the most current technical information.
FRONT VIEW
(Reference Spare Parts List in this manual)
A
CCESS PANEL
13
UPPER
FRONT
10
FRONT
GRILLE
15
COVER
12
CASTERS
16
KEYPAD
11
SIDE
14
