Kodiak G03 series - REFRIGERATION DIAGRAM; Refrigeration Cycle Schematic; Component Identification

Kodiak Recirculating Chiller Technical Manual
Manual # 820-0109, Rev. Y, 07/08/10 - 44 - Check Lytron’s website www.Lytron.com
for the most current technical information.
REFRIGERATION DIAGRAM
