TP-6805 8/1544 Section 4 Controller
SiteTech Group Notes [
Default
Setting
Adjustment
Range *
UnitsParameter
Genset System
Configuration
Genset System Voltage V 110 -- 600 240.0
Genset System Frequency Hz 50/ 60 60.0
Genset Voltage Phase
Connection
Dropdown menu Single
Phase
Genset Power Rating kW DO NOT CHANGE
Auto
select
based on
genset
model and
fuel type
Genset Rated Current A Read Only Load
Mgmt
w
Genset System Battery Voltage V 12 / 24 12
Prime Power Application Standby or prime Standby N/A
Current Transformer Ratio Locked 400 Load
Mgmt
w
Local Start Mode Read Only Off
Measurement System English or metric English
ECM Power True or False False N/A
Display Contrast 0 -- 100 50
Genset System Language No effect. English N/A
Genset Maximum Percent
Capacity
% 0 -- 120 70.0
Load
Mgmt
w
Generator Overloaded Percent % 0 -- 120 85.0
Under Frequency Shed Level Hz 0--5 0.5
Base Load Add Time s 10 -- 2400 60
Base Over Load Shed Time s 2--30 30
Base Under Frequency Shed
Time
s 1--20 5
Genset Fuel Type (firmware
versions 4.5 or higher)
Natural Gas or LP
(pulldown)
Natural
Gas
Automatic Start Minimum Voltage V 15 -- 60 51
Automatic Stop Minimum Percent
Load
% 0 -- 100 20
Automatic Start Minimum Voltage
Delay
s 1 -- 3600 180
Automatic Stop Minimum Load
Delay
s 1 -- 3600 180
ECM Powered Mode On or Off Off
Genset Calibration
Genset Calibration Factor Voltage
L1-L2
0.9 -- 1.1 1.0063
Genset Calibration Factor Voltage
L2-L3
0.9 -- 1.1 0.9909 3-phase
Genset Calibration Factor Voltage
L3-L1
0.9 -- 1.1 0.9427 3-phase
Genset Calibration Factor Current
L1
0.9 -- 1.1 1.000000 Load
Mgmt
w
Genset Calibration Factor Current
L2
0.9 -- 1.1 1.000000 N/A
* Read Only = Not adjustable
[ Notes indicate applicability to genset model and accessories. N/A = Not applicable to these generator s ets.
] See TT-1584 for more information about digital inputs and outputs.
w Load management device (LCM, load shed kit, or RXT with combined interface/ load management board)
