TP-6805 8/15 45Section 4 Controller
SiteTech Group Notes [
Default
Setting
Adjustment
Range *
UnitsParameter
Advanced Speed Control
Proportional Gain
Factory set per unit.
DO NOT ADJUST unless instructed by the
Kohler Generator Service Department.
Transient Integral Gain
Derivative Gain
Slow Correction Integral Gain
Diagnostic Derivative Gain
Diagnostic Transient Integral
Gain
Voltage Regulator
Voltage Regulator Average
Voltage Adjustment
V 108 -- 660
(Auto select with
system voltage)
240.0
(System
Voltage)
Voltage Regulator Volts Per Hertz
Slope
% 1-- 10 5
Voltage Regulator Volts Per Hertz
Cut In Frequency
Hz 42 -- 62 59
Voltage Regulator Gain 1 -- 255 16
Voltage Regulator Firmware
Version
Read Only N/A N/A
Engine Timing
Engine Start Delay s 0 -- 300 0
Engine Cool Down Delay s 300 -- 600 300
Engine Crank On Delay s 10 -- 30 15
Engine Crank Pause Delay s 1--60 15
Engine Number Of Crank Cycles 1--6 3
Genset Protection
Genset Low Battery Voltage
Warning Delay
s Read Only 90
Genset High Battery Voltage
Warning Delay
s Read Only 10
Genset Low Battery Voltage
Warning Limit
% 80 -- 100 100
Genset High Battery Voltage
Warning Limit
% 110 -- 135 125
Genset Battery Low Cranking
Voltage Warning Delay
s Read Only 6
Genset Battery Low Cranking
Voltage Warning Limit
% Read Only 60
Engine Protection
Engine Low Oil Pressure
Shutdown Delay
s 5 5
Engine Locked Rotor Shutdown
Delay
s 3 3
Genset Low Engine Speed
Shutdown Limit
% 75 -- 95 85
Genset High Engine Speed
Shutdown Limit
% 105 -- 120 115
Engine Low Oil Pressure Warning
Limit
kPa No effect. N/A
Engine High Oil Pressure
Shutdown Limit
kPa No effect. N/A
* Read Only = Not adjustable
[ Notes indicate applicability to genset model and accessories. N/A = Not applicable to these generator s ets.
] See TT-1584 for more information about digital inputs and outputs.
w Load management device (LCM, load shed kit, or RXT with combined interface/ load management board)
