Kohler 20RESC User Manual

TP-6805 8/1546 Section 4 Controller
SiteTech Group Notes [
Default
Setting
Adjustment
Range *
UnitsParameter
Generator Protection
Loss Of AC Sensing Shutdown
Delay
s Read Only 3
Genset Low Voltage Shutdown
Delay
s Read Only 10
Genset High Voltage Shutdown
Delay
s Read Only 2
Genset Low Voltage Shutdown
Limit
% Read Only 80
Genset High Voltage Shutdown
Limit
% Read Only 120
Genset Short Term Low
Frequency Shutdown Delay
s Read Only 10
Genset Long Term Low
Frequency Shutdown Delay
s Read Only 60
Genset High Frequency
Shutdown Delay
s Read Only 10
Genset Low Frequency
Shutdown Limit
% Read Only 90
Genset High Frequency
Shutdown Limit
% Read Only 110
Digital Input A1
Digital Input A1 Value Read Only False N/A
Digital Input A1 Enabled True or False True N/A
Digital Input A1 Event See dropdown list in
SiteTech.
]
Fuel
Pressure
Low
Warning
N/A
Digital Input A2
Digital Input A2 Value Read Only False N/A
Digital Input A2 Enabled True or False True N/A
Digital Input A2 Event See dropdown list in
SiteTech.
]
Auxiliary
Input
Warning
N/A
Digital Input B1
Digital Input B1 Value Read Only False
PIM
Digital Input B1 Enabled True or False False
Digital Input B1 Event See dropdown list in
SiteTech.
]
None (0)
Digital Input B2
Digital Input B2 Value Read Only False
PIM
Digital Input B2 Enabled True or False False
Digital Input B2 Event See dropdown list in
SiteTech.
]
None (0)
Digital Output A1
Digital Output A1 Value Read Only False N/A
Digital Output A1 Event See dropdown list in
SiteTech.
]
NFPA 110
Alarm
Active
N/A
Digital Output A2
Digital Output A2 Value Read Only N/A N/A
Digital Output A2 Event See dropdown list in
SiteTech.
]
N/A N/A
Digital Output B1
Digital Output B1 Value Read Only False
PIM
Digital Output B1 Event See dropdown list in
SiteTech.
]
Generator
Running
* Read Only = Not adjustable
[ Notes indicate applicability to genset model and accessories. N/A = Not applicable to these generator s ets.
] See TT-1584 for more information about digital inputs and outputs.
w Load management device (LCM, load shed kit, or RXT with combined interface/ load management board)

Kohler 20RESC Specifications

General

Rated Output (Gasoline)	20 kW
Rated Output (LPG)	18 kW
Voltage	120/240 V
Frequency	60 Hz
Fuel Type	Gasoline, LPG, Natural Gas
Starting System	Electric
Warranty	5 years limited
Dimensions	48.5 in L x 29 in H
