TP-6805 8/1548 Section 4 Controller
SiteTech Group Notes [
Default
Setting
Adjustment
Range *
UnitsParameter
ATS Connection
Configuration
ATS Source Read Only N/A RXT
Source 1 System
Configuration
Source 1 System Voltage V 110.0 -- 600.0
(Auto select with
system voltage)
Genset
System
Voltage
RXT
Source 1 System Frequency Hz 48.0 -- 62.0
(Auto select with
system frequency)
Genset
System
Frequency
Source 1 Voltage Debounce
Delay
s 1--99 0.5
Source 1 Low Voltage Pickup % 85 -- 100 90
Source 1 Low Voltage Dropout % 75 -- 98 90
Source 1 Calibration
Source 1 Calibration Factor
Voltage L1-L2
Read Only 1
RXT
Source 1 Calibration Factor
Voltage L2-L3
Read Only 1
Source 1 Calibration Factor
Voltage L3-L1
Read Only 1
Source 2 System
Configuration
Source 2 System Voltage V 110.0 -- 600.0
(Auto select with
system voltage)
Genset
System
Voltage
RXT
Source 2 System Frequency Hz 48.0 -- 62.0
(Auto select with
system frequency)
Genset
System
Frequency
Source 2 Voltage Debounce
Delay
s 0.1 -- 9.9 0.5
Source 2 Low Voltage Pickup % 85 -- 100 90
Source 2 Low Voltage Dropout % 75 -- 98 90
Source 2 Calibration
Source 2 Calibration Factor
Voltage L1-L2
Read Only 1
RXT
Source 2 Calibration Factor
Voltage L2-L3
Read Only 1
Source 2 Calibration Factor
Voltage L3-L1
Read Only 1
ATS Exercise
Exercise Interval Weekly or
Every Other Week
Weekly
RXT
Exercise Run Duration min 10 -- 30 20
Exercise Mode Pulldown
See List
Unloaded
Cycle (2)
Exercise Warning Enabled True or False True
ATS Delays
ATS Transfer From Preferred
Delay
s 1--10 3
RXT
ATS Transfer From Standby
Delay
s 1 -- 600 120
ATS Source 2 Engine Start Delay s 1--10 3
Modbus Is Modbus Master True or False False
* Read Only = Not adjustable
[ Notes indicate applicability to genset model and accessories. N/A = Not applicable to these generator s ets.
] See TT-1584 for more information about digital inputs and outputs.
w Load management device (LCM, load shed kit, or RXT with combined interface/ load management board)
