Kohler 25CCL User Manual

TP-6694 6/22 165
Description
Controller
Display
Message
Write
Access
Display
SiteTech
GenSet
Mode
Always
Running
Stopped
Range
Setting
Default
Selection
Time
Delay
Range
(sec.)
Default
Time
Delay
(sec.)
Programmer-
Defined
Settings
Charger Equalize Stage
Duration (Min)
Note:
Equalize is only
available with
FLA/VRLA topology
selected.
S
A
60–480
Charger Manual
Equalize Cycle
Activation
Note:
Equalize is only
available with
FLA/VRLA topology
selected.
S
A
Active
Inactive
Inactive
Charger Maximum
Absorption Time
Threshold (Min.)
S
A
60–360
60–600
(NiCad
only)
240
Adjustable with
Charger
Custom Profile
enabled.
Charger Maximum Bulk
Time Threshold (Min)
S
A
60–600
480
Adjustable with
Charger
Custom Profile
enabled.
Charger Refresh
Charge Cycle Time (Hr)
S
A
0,
23–672
335
Adjustable with
Charger
Custom Profile
enabled.
Charger Return To Bulk
State Voltage Threshold
(V)
S
A
10–13
(12 V)§
20–26
(24 V)§
12.8
(12 V)
25.6
(24 V)
Charger Starter Battery
Topology
Note:
Verify that the battery
topology is set correctly
for the battery type that
is used. Incorrect
charger output system
voltage may cause
irreversible damage to
the battery and
abnormal out gassing.
S
A
Default
FLA/VRLA
AGM Gel
NiCad
Default
Charger System Battery
Voltage
Note:
Verify that the system
voltage is set correctly
for the battery type that
is used. Incorrect
charger output system
voltage may cause
irreversible damage to
the battery and
abnormal out gassing.
S
A
System 12
VDC
System 24
VDC
12 VDC
Charger Temperature
Compensation Enable
S
A
Active
Inactive
Inactive
Charger Temperature
Compensation Slope
(mV/°C)
S
A
-40–0
(12 V)
-80–0
(24 V)
-30
(12 V)
-60
(24 V)
Adjustable with
Charger
Custom Profile
enabled.
Charger Voltage
Absorption (V)
S
A
13–15
(12 V)§
26–30
(24 V)§
14.25
(12 V)
28.5
(24 V)
Adjustable with
Charger
Custom Profile
enabled.
