164 TP-6694 6/22
Description
Controller
Display
Message
Write
Access
Display
SiteTech
GenSet
Mode
Always
Running
Stopped
Range
Setting
Default
Selection
Time
Delay
Range
(sec.)
Default
Time
Delay
(sec.)
Programmer-
Defined
Settings
Ground fault input *
Ground Fault
Warning
Not adjustable
kW overload
Total Power
High Shutdwn
Fixed
102%
standby,
112%
prime
Fixed
60
Not adjustable
Locked rotor (failed to
crank)
Locked Rotor
Shutdwn
S
A
1--5
5
Overfrequency
Freq High
Shutdwn
102-140%
110%
Fixed
10
Not adjustable
Overvoltage (each
phase)
Volts (L1-L2,
L2-L3, or L3-
L1) High
Shutdwn
S
A
105-135%
120%
2-10
2
Power rating
Pwr Rating
DS
S
10-5000
275
System frequency
System Freq
DS
S
50-60
60
System voltage
System Volt
DS
S
110-600
208
Underfrequency
Frequency Low
Shutdwn
80-95%
90%
Fixed
10 ST
60 LT
Not adjustable
Undervoltage (each
phase)
Volts (L1-L2,
L2-L3, or L3-
L1) Low
Shutdwn
S
A
70-95%
80%
5-30
10
Voltage/phase
configuration, 0-Single
phase, 1-Single Phase
dogleg, 2-three phase
wye, 3-three phase
delta
SystemPhase
DS
S
0-3
2
Voltage regulator
average voltage
adjustment
VR Volt Adj
DS
R
108-600
208
Voltage) regulator
communication loss
RegCommLoss
Shutdwn
Not adjustable
SiteTech Read/Write Display Only
Charger Absorption
Current Termination
Target (A)
S
A
1-5
2
Charger Automatic
Equalize Enable
Note:
Equalize is only
available with
FLA/VRLA topology
selected.
S
A
Active
Inactive
Inactive
Charger Charge Cycles
Between Auto Equalize
Cycles
Note:
Equalize is only
available with
FLA/VRLA topology
selected.
S
A
0–99
Adjustable with
Charger
Custom Profile
enabled.
Charger Custom Profile
Enable
S
A
Active
Inactive
Inactive
Charger Depleted
Battery Current Limit
S
A
1–5
2
Charger Depleted
Battery Voltage Target
S
A
4–12
(12 V)
18–24
(24 V)
10 (12 V)
20 (24 V)
Adjustable with
Charger
Custom Profile
enabled.
