5-4 Wiring Diagrams TP-5393 9/93
WARNING
Accidental starting.
Can cause severe injury or death.
Disconnect battery cables before working on
generator set (negative lead first and reconnect it
last).
Accidental starting can cause severe injury or
death. Turn generator master switch to OFF position,
disconnect power to battery charger, and remove
battery cables (remove negative lead first and
reconnectitlast)todisablegeneratorsetbeforeworking
on any equipment connected to generator. The
generator set can be started by automatic transfer
switch or remote start/stop switch unless these
precautions are followed.
WARNING
Hazardous voltage.
Do not operate generator set without all guards
and electrical enclosures in place.
Moving rotor.
Can cause severe injury or death.
Hazardous voltage can cause severe injury or
death. Perform electrical service only as prescribed in
equipment manual. Be sure that generator is properly
grounded. Never touch electrical leads or appliances
with wet hands, when standing in water, or on wet
ground as the chance of electrocution is especially
prevalent under such conditions. Wiring should be
inspected at the interval recommended in the service
schedule—replace leads that are frayed or in poor
condition. The function of a generator set is to produce
electricity and wherever electricity is present, there is
the hazard of electrocution.
