TP-5393 9/93 Installation 6-25
Do not connect to any building electrical system
without connecting through an approved device
and after building main switch is open.
WARNING
Hazardous voltage.
Backfeed to utility system can cause severe
injury, death, or property damage.
Hazardous “backfeed” voltage can cause severe
injury or death. The generator must not be used to
“backfeed” by connecting it to building/campground
circuits. Install a transfer switch in standby power
installationstoprevent connectionof standbyandother
sources of power. Electrical backfeed into a utility
electrical system can cause serious injury or death to
utility personnel working on transmission lines.
Remote Switch Connection
Kohler offersa remoteswitchpanelformounting onthe
dashboardorelsewhereinthevehicle.Itmeasures2in.
x 4 in. (51 mm x 103 mm) and requiresa cutoutof 13/4
in. x 3 1/4 in. (44 mm x 83 mm). The panel includes
start-stop switch, generator ON light, and a digital
hourmeter. Kohler also offers wiring harnesses of
different lengths with keyed plugs or pigtails for quick
connection between the controller on the set
(Figure 6-27) and the remote-switch panel in the
vehicle. Part numbers of these are listedin the chart on
the following page. The wiring diagram shown in
Figure 6-28 may be useful if the installer elects to use
justastart-stopswitchorseparatelightsandhourmeter.
1-905
1
1. Remote Connection
Figure 6-27. Controller—Remote Connection
To Next Page
