TP-6772 2/14b34 Section 2 Operation
Menu Summary List (Legend: D First level submenu, d second level submenu)
Prime
Menu
D See Section 2.10.10
Volt Select
Menu
D Volt Select: *
d 120/240 V 1 Ph
d 120/208 V 3 Ph
d 139/240 V 3 Ph
d 277/480 V 3 Ph
d 120/240 V 3 Ph
d 115/230 V 1 Ph
d 120 V 1 Ph
d 230 V 1 Ph
d 240 V 1 Ph
d 110/190 V 3 Ph
d 127/220 V 3 Ph
d 115/230 V 3 Ph
d 230/400 V 3 Ph
d 240/416 V 3 Ph
USB
Menu
D See Section 2.10.12 for
USB flowchart information
D System Frequency
D Battery DC Voltage
D CAN A (J1939,
SmartCraft, NMEA 2000) *
D Measurement System
(Metric or English) *
D Contrast (display) *
Voltage Regulator
Menu
D Voltage Regulator Voltage
Adjust *
D Volt/Hz Adjust *
D Gain Adjust *
D Stability Adjust *
D Reset Voltage Regulator
Settings *
d Reset Voltage
Regulator?
Event Log
Menu
D See Section 2.6.6 for a list
of items that can appear
in Event Log
Overview
Menu
Generator Metering
Menu
Available as scrolling or
fixed display text
D Active Shutdowns (if
present)
D Active Warnings (if
present)
D Genset State
D Average Volts
Line-to-Line
D Frequency
D Coolant Temperature
D Oil Pressure
D Battery DC Voltage
D Engine Run Time
D Next Maintenance
D Software Version
Engine Metering
Menu
D Engine Speed
(Tachometer)
D Oil Pressure
D Coolant Temperature
D Battery DC Voltage
D Volts, L1--L2 *
D Volts, L2--L3 *
D Volts, L3--L1 *
D Volts, L1--N *
D Volts, L2--N *
D Volts, L3--N *
D Frequency
D Reset Calibration (User
can reset individual volt
values or reset all values)
GenSet Information
Menu
D Generator Set Model No.
D Generator Set Serial No.
D Controller Serial No.
GenSet Run Time
Menu
D Engine Run Time
D Engine Starts
D Next Maintenance
GenSet System
Menu
* User-Defined (Changeable) Menu Displays. NOTE: Some changes require activating the calibration or adjustment mode. Some displays may
only appear when in the calibration or adjustment mode. Refer to Section 2.10 Reviewing Menu Displays to activate the calibration or adjustment
mode.
