TP-6842 7/15 Section 1 Installation 25
1.13.2 Auto Start Volt
This value is the voltage at which the 6VSG will
automatically start. The automatic start criteria are
met when this voltage has reached or fallen below this
value for the specified delay period (standard
3 minutes, only changed using SiteTech). This
voltage is detected at the generator and may differ
from the voltage measured at the load or the battery
due to voltage drop in the lines.
Figure 1-25
Figure 1-24 Auto Start Voltage Settings
1.13.3 Auto Stop Load
This value is the load level at which the 6VSG will
automatically stop. The automatic stop criteria are met
when the load has reached or fallen below this value
for the specified delay period (standard 3 minutes and
only changed using SiteTech). This load is detected at
the generator.
Figure 1-26
Figure 1-25 Auto Stop Load Settings
1.13.4 Load Limit
This value is the limit to the generator capacity. This
allows the 6VSG to limit current output to the
maximum charge rate specified by the battery
manufacturer or load in the application. Adjustments
should be done by qualified individuals after referring
to battery manufacturer’s recommended maximum
charge rate.
Figure 1-27
Figure 1-26 Load Limit
1.13.5 Delay (seconds)
This delay is used to determine the amount of time a
value (Auto Start Volt or Auto Stop Load) needs to be
sustained before the respective action is taken
pertaining to the value. The delay can only be
changed using a personal computer (laptop) and
Kohler SiteTech software. Contact an authorized
Kohler distributor or dealer to adjust the setting, if
necessary.
Figure 1-28
Figure 1-27 Auto Start/Auto Stop Delay Settings
6VSG-24V 6VSG-36V 6VSG-48V
Default 25 VDC 37.5 VDC 50 VDC
Minimal value 15 VDC 15 VDC 15 VDC
Maximal value 60 VDC 60 VDC 60 VDC
6VSG-24V 6VSG-36V 6VSG-48V
Default 40% 40% 40%
Minimal value 0% 0% 0%
Maximal value 100% 100% 100%
6VSG-24V 6VSG-36V 6VSG-48V
Default 100% 100% 100%
Minimal value 0% 0% 0%
Maximal value 120% 120% 120%
Load limit =
(Charge voltage x Charge current)
60
6VSG-24V 6VSG-36V 6VSG-48V
Default 3 minutes 3 minutes 3 minutes
Minimal value 1 second 1 second 1 second
Maximal value 60 minutes 60 minutes 60 minutes
