Kohler 7000 Series Service Manual

11
Specifi cations
32 690 03 Rev. I KohlerEngines.com
Engine Dimensions with PRO Performance Air Cleaner-Oil Filter Side
A
B
C
D
E
F
G
H
I
L
M
K
J
A
458.7 mm (18.06 in.)
Air Cleaner
Removal
B
398.7 mm (15.70 in.)
Top of Air Cleaner
C
265.2 mm (10.44 in.)
Evap Connection
Point
D
166.5 mm (6.56 in.)
Center of Gravity
E
Engine Mounting
Surface
F
80.3 mm (3.16 in.)
Oil Filter
G Mounting Hole "A" H
51.2 mm (2.02 in.)
Oil Filter
I
134.0 mm (5.28 in.)
Spark Plug Center
Line
J 340.9 mm (13.42 in.) K 380.7 mm (14.99 in.) L Optional Fixed Guard
M
272.0 mm (10.71 in.)
Evap Connection
Point
