Kohler 7000 Series Service Manual

28
Air Cleaner/Intake
KohlerEngines.com 32 690 03 Rev. I
NOTE: Operating engine with loose or damaged air
cleaner components could cause premature
wear and failure. Replace all bent or damaged
components.
NOTE: Paper element cannot be blown out with
compressed air.
Rotate air cleaner cover levers outward to unlock cover;
remove air cleaner cover.
or
Move bails on air cleaner cover up; remove latches from
cover; remove cover.
Precleaner (if equipped)
1. Remove precleaner from paper element.
2. Replace or wash precleaner in warm water with
detergent. Rinse and allow to air dry.
3. Lightly oil precleaner with new engine oil; squeeze
out excess oil.
4. Reinstall precleaner over paper element.
Paper Element
1. Remove element from base; service precleaner.
Discard element.
2. Install precleaner over new paper element and install
on base.
Position air cleaner cover with levers outward over air
cleaner; turn levers inward to lock.
or
Reinstall cover; place latches onto cover; pull down bails
to secure cover.
AIR CLEANER
These systems are CARB/EPA certifi ed and components
should not be altered or modifi ed in any way.
Air Cleaner Components
C
C
B
B
H
D
E
E
F
F
B
J
E
K
K
F
A
G
I
A
Low-Profi le Air
Cleaner (LPAC)
B Air Cleaner Cover
C
Air Cleaner Cover
Lever
D LPAC Element
E Precleaner F Air Cleaner Base
G
High Performance
Air Cleaner
H
High Performance
Element
I
PRO Performance
Air Cleaner
J
PRO Performance
Element
K Bail
