4 — PROGRAMMABLE PARAMETERS
pg. 93
Return to TOC Curtis AC F2-A, F4-A, F6-A Motor Controllers – FOS 4.5 – April 2022
APPLICATION SETUP/HYDRAULICS — LIFT SETTINGS MENU
PARAMETER ALLOWABLE RANGE DEFAULT DESCRIPTION
Lift Input
Lift_Pot_Percent
0x3045 0x00
0.0 – 100.0 %
0 – 1000
Read Only Lift pot input after source selection and before mapping as
a percentage.
Mapped Lift Throttle
Mapped_Lift_Throttle
0x4FD8 0x00
0.0 – 100.0 %
0 – 32767
Read Only Hydraulics lift throttle after mapping.
Lift Command
Hydraulic_Lift_Throttle
0x3C25 0x00
0.0 – 100.0 %
0 – 32767
Read Only Pump demand after input processing.
Lift Min Input
Lift_Deadband_Percent
0x3708 0x00
0 – 100 %
0 – 1000
15 % Input voltage percentage below which throttle is made 0.
Lift Max Input
Lift_Max_Percent
0x370B 0x00
0 – 100 %
0 – 1000
85 % Input value corresponding to 100% throttle.
Lift Map Shape
Lift_Map
0x370A 0x00
0 – 100 %
0 – 32767
35 % Denes sensitivity of input. Lower value results in lesser output
variation to input. Set at 50% for linear response.
Lift Offset
Lift_Offset
0x370C 0x00
0 – 100 %
0 – 32767
0 % Minimum lift throttle command after input becomes greater than
Lift_Deadband_Percent parameter.
Lift Limit Switch Source
Lift_Limit_Source
0x3C3E 0x00
0 – 35
0 – 35
0 The switch input name (number) to which the limit switch
is applied.
Lift Limit Switch Type
Lift_Limit_Type
0x3C3F 0x00
0 – 3
0 – 3
0 Describes the limit switch type:
0 - Normally Open (NO) Switch
1 - Normally Closed (NC) Switch
2 - Voltage Input (Turns off the pump if input > 50%)
Lift Battery Lockout
Lift_BDI_Lockout
0x3707 0x00
0 – 100 %
0 – 100
0 % Battery state of charge (BDI) threshold below which pump turn-on
is disabled.
