5 — SYSTEM MONITOR MENU
Curtis AC F2-A, F4-A, F6-A Motor Controllers – FOS 4.5 – April 2022 Return to TOC
pg. 148
5 — SYSTEM MONITOR MENU
e numbered I/O is controller model specic. See Tables 6 and 7.
Table 19 System Monitor Variables
COMMAND INPUTS MENU.......... p. 149
— Throttle Input
Mapped Throttle
— Throttle Multiplier
— Throttle Command
— Brake Input
— Mapped Brake
— Brake Command
— Lift Input
— Mapped Lift Throttle
— Lift Command
— Lower Input
— Mapped Lower Throttle
— Lower Command
— Interlock
— EMR Input Active
BATTERY MENU............................. p.156
— BDI
Keyswitch Voltage
Capacitor Voltage
— Battery Current
— Battery Power
MOTOR MENU............................ p.156
— Motor RPM
— Temperature
Motor Torque
— Motor Power
Feedback A
— Feedback B
— Rotor Position
CONTROLLER MENU...................... p.154
— Current (RMS)
— Modulation Depth
— Electrical Frequency
Controller Temperature
— Capacitor Bank Temperature
— Main Contactor State
— Precharge State
— EM Brake State
— EMR State
— NMT State
— Regen
Internal Timer
— CUTBACKS........................ p. 155
— Mo tor Temperature Cutback
Co ntroller Temperature
Cutback
— Ca pacitor Bank
Temperature Cutback
— Undervoltage Cutback
— Overvoltage Cutback
— LF Cutback
— Battery Current Cutback
— Overall Cutback
— Traction FET Max Temp
Traction FET Max Temp Low
Traction FET Max Temp High
MOTOR TUNING ................ p.155
— Motor RPM
— Base Speed Captured
Test Field Current
VEHICLE MENU.......................... p.157
— Vehicle Speed
— Vehicle Odometer
Trip Odometer 1
Trip Odometer 2
— Vehicle Acceleration
Time to Speed 1
Time to Speed 2
Time Between Speeds
Time to Dist 1
Time to Dist 2
Time to Dist 3
— Braking Distance Captured
— Distance Since Stop
— Distance Fine
FAULT HISTORY.......................... p. 158
SWITCH STATUS MENU............. p. 151
— Switch 1
:
— Switch 31
HARDWARE INPUTS MENU......... p.150
— Analog 1
:
— Analog 31
— Pot 1 Resistance
— Pot 18 Resistance
— Pot 6 Resistance
— Pot 19 Resistance
OUTPUTS MENU........................ p.153
— Driver 1 PWM
:
— Driver 7 PWM
— Driver 1 Current
:
— Driver 7 Current
— External 5V
— External 12V
— External 5V Current
— External 12V Current
