Page #158 background imageLoading...
Page #158 background image
5 — SYSTEM MONITOR MENU
Curtis AC F2-A, F4-A, F6-A Motor Controllers – FOS 4.5 – April 2022 Return to TOC
pg. 150
SYSTEM MONITOR / INPUTS MENU: HARDWARE INPUTS
VARIABLE DISPLAY RANGE DESCRIPTION
1
Analog 1
analog_input_volts_1
0x3B2E 0x00
–327.68 – 327.67V
–32768 – 32767
Voltage at analog 1 (pin 16).
Analog 2
analog_input_volts_2
0x3B2F 0x00
–327.68 – 327.67V
–32768 – 32767
Voltage at analog 2 (pin 8) (e.g., the Motor Temp Sensor).
Analog 3
analog_input_volts_3
0x3B30 0x00
–327.68 – 327.67V
–32768 – 32767
Voltage at analog 3 (pin 31).
Note: Typically used as the Encoder A input; therefore will track the
encoder pulses.
Analog 4
analog_input_volts_4
0x3B31 0x00
–327.68 – 327.67V
–32768 – 32767
Voltage at analog 4 (pin 32).
Note: Typically used as the Encoder B input; therefore will track the
encoder pulses.
Analog 5
analog_input_volts_5
0x3B32 0x00
–327.68 – 327.67V
–32768 – 32767
Voltage at analog 5 (Input 5: Switch 5, pin 9).
Analog 6
analog_input_volts_6
0x3B33 0x00
–327.68 – 327.67V
–32768 – 32767
Voltage at analog 6 (Input 6: Pot 6 Supply, pin 15).
Analog 7
analog_input_volts_7
0x3B34 0x00
–327.68 – 327.67V
–32768 – 32767
Voltage at analog 7 (Input 7: Switch 7, pin 22).
Analog 8
analog_input_volts_8
0x3B35 0x00
–327.68 – 327.67V
–32768 – 32767
Voltage at analog 8 (Input 8: Switch 8, pin 33).
Analog 14
analog_input_volts_14
0x3B38 0x00
–327.68 – 327.67V
–32768 – 32767
Voltage at analog 14 (Input 14: +12V Ext Supply, pin 25).
Analog 18
analog_input_volts_18
0x3B60 0x00
–327.68 – 327.67V
–32768 – 32767
Voltage at analog 18 (Input 18: Pot 18 Wiper, pin 17).
Analog 19
analog_input_volts_19
0x3B61 0x00
–327.68 – 327.67V
–32768 – 32767
Voltage at analog 19 (Input 19: Pot 19 Supply, pin 27).
Analog 31
analog_input_volts_31
0x3B56 0x00
–327.68 – 327.67V
–32768 – 32767
Voltage at analog 31 (Input 31: +5V Ext Supply, pin 26).
Pot 1 Resistance
Pot_1_resistance
0x32E2 0x00
0 – 10k Ω
–32768 – 32767
The dynamically calculated resistance of a connected potentiometer.
Pot 18 Resistance
Pot_18_resistance
0x337E 0x00
0 – 10k Ω
–32768 – 32767
The dynamically calculated resistance of a connected potentiometer.
Pot 6 Resistance
Pot_6_resistance
0x3314 0x00
0 – 10k Ω
–32768 – 32767
The dynamically calculated resistance of a connected potentiometer.
Pot 19 Resistance
Pot_19_resistance
0x3318 0x00
0 – 10k Ω
–32768 – 32767
The dynamically calculated resistance of a connected potentiometer.
1
Pin number is on a 35-pin controller basis. For 23-pin controllers, use the variable name (see Fig. 12).
