4 — PROGRAMMABLE PARAMETERS
Curtis AC F2-A, F4-A, F6-A Motor Controllers – FOS 4.5 – April 2022 Return to TOC
pg. 108
CONTROLLER SETUP — INPUTS MENU, cont’d
PARAMETER ALLOWABLE RANGE DEFAULT DESCRIPTION
Analog 3 menu
Voltage
Analog_Input_Volts_3
0x3B30 0x00
–327.68 – 327.67V
–32768 – 32767
Read Only Voltage at the analog 3 input (as the motor encoder-A signal in
Fig 13).
Percent
Analog_Input_Percent_3
0x3B3B 0x00
0.0 – 100.0 %
0 – 1000
Read Only Voltage on a 0-100 percentage basis.
The percentage of the voltage at the input pin is based upon the
High and Low settings, i.e., the percent of:
[(analog_input_volts_3) – (analog_input_3_low)] /
[(analog_input_3_high) – (analog_input_3_low)]
Low
Analog_Input_3_Low
0x32F7 0x00
0.0 – 7.0V
0 – 700
0.0V The minimum input voltage before a fault is declared.
This voltage represents the 0% point for the normalized inputs.
High
Analog_Input_3_High
0x32F8 0x00
0.0 – 7.0V
0 – 700
5.0V The maximum input voltage before a fault is declared.
This voltage is the 100% point for the normalized inputs.
Fault Tolerance
Analog_Input_3_Fault_Tolerance
0x331C 0x00
0.0 – 11.0V
0 – 1100
0.0V Species the voltage threshold above the congured high limit
or below the low limit, exceeding this results in an analog out of
range fault.
For example, if High = 9.6V, Low = 1V and Tolerance = 0.2V, an
input voltage between 1V to 9.6V is mapped to 0–100%.
Voltages above 9.8V (9.6 + 0.2) or below 0.8V (1V – 0.2V) trigger
the fault.
Analog 4 menu
Voltage
Analog_Input_Volts_4
0x3B31 0x00
–327.68 – 327.67V
–32768 – 32767
Read Only Voltage at the analog 4 input (as the motor encoder-A signal in
Figure 13).
Percent
Analog_Input_Percent_4
0x3B3C 0x00
0.0 – 100.0 %
0 – 1000
Read Only Voltage on a 0-100 percentage basis.
The percentage of the voltage at the input pin is based upon the
High and Low settings, i.e., the percent of:
[(analog_input_volts_4) – (analog_input_4_low)] /
[(analog_input_4_high) – (analog_input_4_low)]
Low
Analog_Input_4_Low
0x32F9 0x00
0.0 – 7.0V
0 – 700
0.0V The minimum input voltage before a fault is declared.
This voltage represents the 0 % point for the normalized inputs.
High
Analog_Input_4_High
0x32FA 0x00
0.0 – 7.0V
0 – 700
5.0V The maximum input voltage before a fault is declared.
This voltage is the 100 % point for the normalized inputs.
Fault Tolerance
Analog_Input_4_Fault_Tolerance
0x331D 0x00
0.0 – 11.0V
0 – 1100
0.0V Species the voltage threshold above the congured high limit
or below the low limit, exceeding this results in an analog out of
range fault.
For example, if High = 9.6V, Low = 1V and Tolerance = 0.2V, an
input voltage between 1V to 9.6V is mapped to 0–100%.
Voltages above 9.8V (9.6 + 0.2) or below 0.8V (1V – 0.2V) trigger
the fault.
Analog 5 menu
Voltage
Analog_Input_Volts_5
0x3B32 0x00
–327.68 – 327.67V
–32768 – 32767
Read Only Voltage at the analog 5 input (Input 5).
