CONTROLLER SETUP — INPUTS MENU, cont’d
PARAMETER ALLOWABLE RANGE DEFAULT DESCRIPTION
Analog 14 menu
Voltage
Analog_Input_Volts_14
0x3B38 0x00
–327.68 – 327.67V
–32768 – 32767
Read Only Voltage at the analog 14 input (Input 14). (as the +12V External
Supply in Fig 13).
Percent
Analog_Input_Percent_14
0x3B42 0x00
0.0 – 100.0 %
0 – 1000
Read Only Voltage on a 0-100 percentage basis.
The percentage of the voltage at the input pin is based upon the
High and Low settings, i.e., the percent of:
[(analog_input_volts_14) – (analog_input_14_low)] /
[(analog_input_14_high) – (analog_input_14_low)]
Low
Analog_Input_14_Low
0x3303 0x00
0.0 – 30.0V
0 – 3000
0.0V The minimum input voltage before a fault is declared.
This voltage represents the 0 % point for the normalized inputs.
High
Analog_Input_14_High
0x3306 0x00
0.0 – 30.0V
0 – 3000
30.0V The maximum input voltage before a fault is declared.
This voltage is the 100% point for the normalized inputs.
Fault Tolerance
Analog_Input_14_Fault_
Tolerance
0x3379 0x00
0.0 – 11.0V
0 – 1100
0.0V Species the voltage threshold above the congured high limit
or below the low limit, exceeding this results in an analog out of
range fault.
For example, if High = 9.6V, Low = 1V and Tolerance = 0.2V, an
input voltage between 1V to 9.6V is mapped to 0–100%.
Voltages above 9.8V (9.6 + 0.2) or below 0.8V (1V – 0.2V) trigger
the fault.
Analog 18 menu
Analog 18 Type
Analog_Input_18_Type
0x330F 0x00
Enumeration
0 – 3
Voltage Congure the Analog 18 input by throttle or load type.
0 – Voltage (Hall-effect or voltage throttle)
1 – 3-Wire Pot Wiper (3-wire resistive potentiometer throttle)
2 – 2-Wire Pot Wiper (2-wire resistive potentiometer throttle)
3 – Voltage with Supply (a non-throttle load alternative)
Parameters for Analog 18 Voltage selection Reference the Voltage Throttle section, Chapter 6.
Analog 18 Type
Analog_Input_18_Type
0x330F 0x00
Voltage
(selection menu)
– Selecting the Voltage option opens the menu to its corresponding
monitor variables and the low/high parameters.
Voltage
Analog_Input_Volts_18
0x3B60 0x00
–327.68 – 327.67V
–32768 – 32767
Read Only The analog voltage at the analog 18 input (Input 18).
Percent
Analog_Input_Percent_18
0x3B62 0x00
0.0 – 100.0 %
0 – 1000
Read Only The percentage of the voltage at the input pin is based upon the
High and Low settings, i.e., the percent of:
[(analog_input_volts_18) – (analog_input_18_low)] /
[(analog_input_18_high) – (analog_input_18_low)]
Voltage Throttle usage: Reference the Forward Min/Max &
Reverse Min/Max Input parameters located in the Application
Setup » Throttle menu.
Brake input usage: Reference the Brake Min/Max Input
parameters located in the Application Setup » Brake menu.
Low
Analog_Input_18_Low
0x3309 0x00
0.0 – 11.0V
0 – 1100
0.0V The minimum input voltage before a fault is declared. When the
Analog 18 Type selection is voltage, this set point represents the
0% point for the normalized input.
Triggers the Throttle Input fault (0x2210) when the voltage reading
is below this input voltage reading, if Throttle_Source = 18.
Triggers the Brake Input fault (0x2310) when the voltage reading
is below this input voltage reading, if Brake_Source = 18.
