4 — PROGRAMMABLE PARAMETERS
Curtis AC F2-A, F4-A, F6-A Motor Controllers – FOS 4.5 – April 2022 Return to TOC
pg. 146
TEMPERATURE SENSOR-SENSOR MAP MENU
PARAMETER ALLOWABLE RANGE DEFAULT DESCRIPTION
Sensor Resistance 0
Sensor_0
0x3689 0x00
0 – 100000 Ω
0 – 10000000
0 Ω The user dened motor temperature sensor resistance at the
corresponding Temp_0.
For PTC thermistors, this is the resistance for the rst or lowest
temperature in the mapped range (i.e., -40°C).
For NTC thermistors, this is the resistance for the rst or highest
temperature in the mapped range (i.e., 200°C).
Consult the temperature sensor datasheet for this value.
Sensor Resistance 1
Sensor_1
0x368A 0x00
0 – 100000 Ω
0 – 10000000
0 Ω The user dened motor temperature sensor resistance at the
corresponding Temp_1.
This is the second mapped resistance in the low-to-high or high-
to-low temperature range.
Consult the temperature sensor datasheet for this value.
Sensor Resistance 2
Sensor_2
0x368B 0x00
0 – 100000 Ω
0 – 10000000
0 Ω The user dened motor temperature sensor resistance at the
corresponding Temp_2.
This is the third mapped resistance in the low-to-high or high-to-
low temperature range.
Consult the temperature sensor datasheet for this value.
Sensor Resistance 3
Sensor_3
0x368C 0x00
0 – 100000 Ω
0 – 10000000
0 Ω The user dened motor temperature sensor resistance at the
corresponding Temp_3.
This is the fourth mapped resistance in the low-to-high or high-
to-low temperature range.
Consult the temperature sensor datasheet for this value.
Sensor Resistance 4
Sensor_4
0x368D 0x00
0 – 100000 Ω
0 – 10000000
0 Ω The user dened motor temperature sensor resistance at the
corresponding Temp_4.
This is the fth mapped resistance in the low-to-high or high-to-
low temperature range.
Consult the temperature sensor datasheet for this value.
Sensor Resistance 5
Sensor_5
0x3685 0x00
0 – 100000 Ω
0 – 10000000
0 Ω The user dened motor temperature sensor resistance at the
corresponding Temp_5.
This is the sixth mapped resistance in the low-to-high or high-to-
low temperature range.
Consult the temperature sensor datasheet for this value.
Sensor Resistance 6
Sensor_6
0x3686 0x00
0 – 100000 Ω
0 – 10000000
0 Ω The user dened motor temperature sensor resistance at the
corresponding Temp_6.
For PTC thermistors, this is the resistance for the seventh or
highest temperature in the mapped range (i.e., 200°C).
For NTC thermistors, this is the resistance for the seventh or
lowest temperature in the mapped range (i.e., -40°C).
Consult the temperature sensor datasheet for this value.
MOTOR SETUP — TEMPERATURE SENSOR MENU, cont’d
PARAMETER ALLOWABLE RANGE DEFAULT DESCRIPTION
Sensor Offset
MotorTemp_Sensor_Offset
0x3687 0x00
–20 – 20°C
–200 – 200
0°C
Often the motor temperature sensor is placed in the motor at a
location with a known offset to the critical temperature; the offset
can be corrected with this parameter.
The parameter can also be used to correct a known offset in the
sensor itself.
