Kohler Curtis F Series User Manual

7 — DIAGNOSTICS AND TROUBLESHOOTING
Curtis AC F2-A, F4-A, F6-A Motor Controllers – FOS 4.5 – April 2022 Return to TOC
pg. 224
FLASH
CODE
FAULT NAME
(Curtis Integrated Toolkit™)
POSSIBLE CAUSES SET/CLEAR CONDITIONS FAULT ACTIONS
6-8
0x68
VCL Run Time Error
VCL_Run_Time_Error
0x2820
Fault Type(s): 1
1. Runtime errors are defined
using the VCL Error Module
and VCL Error. See the System
Information file:
• Curtis Integrated Toolkit™ »
VCL Studio » Help »
System Information.
2. Using driver control commands in
VCL can lead to VCL runtime errors
if the VCL command and the driver
assignment do not match.
Set: VCL Run Time Error detected.
Clear: Edit the VCL application
software to x this error
condition; ash the new
compiled software and
matching parameter settings;
Reset Controller.
ShutdownAll:
ShutdownMotor
ShutdownMainContactor
ShutdownEMBrake
ShutdownThrottle
ShutdownInterlock
ShutdownDriver1
ShutdownDriver2
ShutdownDriver3
ShutdownDriver4
ShutdownDriver5
ShutdownDriver6
ShutdownDriver7
ShutdownPD
FullBrake
ShutdownPump
ShutdownCoilSupply
ShutdownVehicle
ShutdownLower
ShutdownLift
Dual Drive
Same, both motors
7-1
0x71
OS General
OS_General
0x2831
Fault Type(s): 1
Physical damage from external
sources/events.
Set: Internal controller
fault detected.
Clear: Reset Controller.
ShutdownAll:
ShutdownMotor
ShutdownMainContactor
ShutdownEMBrake
ShutdownThrottle
ShutdownInterlock
ShutdownDriver1
ShutdownDriver2
ShutdownDriver3
ShutdownDriver4
ShutdownDriver5
ShutdownDriver6
ShutdownDriver7
ShutdownPD
FullBrake
ShutdownPump
ShutdownCoilSupply
ShutdownVehicle
ShutdownLower
ShutdownLift
Dual Drive
Same, both motors
7-2
0x72
PDO Timeout
PDO_Timeout
0x2541
Fault Type(s): 1
1. The time between CAN PDO
messages received exceeded the
PDO Timeout Period as dened by
the Event Timer parameter.
2. Adjust PDO Settings. See
Programmer » Application Setup »
CAN Interface » PDO Setups.
Set: Time between CAN PDO
messages received exceeded
the PDO Timeout Period.
Clear: Receive CAN NMT
message, or Reset Controller.
ShutdownInterlock
Dual Drive
Same, both motors
Table 24 Fault Code Troubleshooting Chart, cont’d
