7 — DIAGNOSTICS AND TROUBLESHOOTING
Curtis AC F2-A, F4-A, F6-A Motor Controllers – FOS 4.5 – April 2022 Return to TOC
pg. 232
Table 24 Fault Code Troubleshooting Chart, cont’d
FLASH
CODE
FAULT NAME
(Curtis Integrated Toolkit™)
POSSIBLE CAUSES SET/CLEAR CONDITIONS FAULT ACTIONS
10-2
0xA2
Driver 2 Fault
Driver_2_Fault
0x2161
Fault Type(s):
1 = Driver current exceeded
hardware limits.
2 = Driver current exceeded
congured over-current limits.
3 = Driver commanded PWM
active, using diagnostic pulses.
Voltage measured high, should
be low. Typically caused by
driver failure, or driver pin
short to high.
4 = Driver commanded PWM
active, using diagnostic pulses.
Voltage measured low, should
be high. Either open circuit, or
driver pin short to ground.
5 = Driver commanded PWM is
0, and voltage measured low
(should be high). Either open
circuit, or driver pin short to
ground.
7 = Driver undercurrent -
Monitored current is below
undercurrent threshold.
Fault types 1-2 are always checked.
Fault types 3-5 are only checked
if driver checks are enabled.
1. Open or short on driver load.
2. Dirty connector pins at controller
or contactor coil.
3. Bad connector crimps or
faulty wiring.
4. Driver overcurrent, as set by the
Driver 2 Overcurrent parameter.
5. See Programmer » Controller
Setup » Outputs » Driver 2 » Driver
2 Overcurrent.
Set: Driver 2 is either open or
shorted, or Driver 2 exceeded
its overcurrent setting.
Clear: Correct the open or short,
and then Reset Controller.
ShutdownDriver2
Dual Drive
This Motor:
ShutdownDriver2
Other Motor:
No Action
10-3
0xA3
Driver 3 Fault
Driver_3_Fault
0x2162
Fault Type(s):
1 = Driver current exceeded
hardware limits.
2 = Driver current exceeded
congured over-current limits.
3 = Driver commanded PWM
active, using diagnostic pulses.
Voltage measured high, should
be low. Typically caused by
driver failure, or driver pin
short to high.
4 = Driver commanded PWM
active, using diagnostic pulses.
Voltage measured low, should
be high. Either open circuit, or
driver pin short to ground.
5 = Driver commanded PWM is
0, and voltage measured low
(should be high). Either open
circuit, or driver pin short
to ground.
7 = Driver undercurrent -
Monitored current is below
undercurrent threshold.
Fault types 1-2 are always checked.
Fault types 3-5 are only checked
if driver checks are enabled.
1. Open or short on driver load.
2. Dirty connector pins at controller
or contactor coil.
3. Bad connector crimps or
faulty wiring.
4. Driver overcurrent, as set by the
Driver 3 Overcurrent parameter.
5. See Programmer » Controller
Setup » Outputs » Driver 3 » Driver
3 Overcurrent.
Set: Driver 3 is either open or
shorted, or Driver 3 exceeded
its overcurrent setting.
Clear: Correct the open or short,
and then Reset Controller.
ShutdownDriver3
Dual Drive
This Motor:
ShutdownDriver3
Other Motor:
No Action
