Baseplate material: Aluminum.
Baseplate:
(bottom surface)
Roughness grade of N8 (ISO 1302), with a atness tolerance of 0.3 mm.
Mounting holes: 4x Ø7 mm 2x Ø7mm and 2x Ø7.5 mm
I/O Connection: 35 Pin AMPseal. Mating receptacle
housing: AMP p/n 776164-1.
23 Pin AMPseal. Mating receptacle
housing: AMP p/n 770680-1.
Gold-plated sockets: (default):
AMP p/n 770520-3 (strip form),
7708554-3 (loose piece).
Tin-plated sockets: (do not mate with gold pins)
AMP p/n 770520-1 (strip form),
7708554-1 (loose piece).
Silo plug:
AMP p/n 770678-1.
Hand crimper for wire harness terminals:
AMP p/n 58440-1.
Power Connections:
5x M6x1.0 — 6H ↓ 18 mm.
EMC: Designed to the requirements of EN 12895:2015.
Safety: Designed to the requirements of:
EN 1175-1:1998+A1:2010.
EN ISO 13849-1:2015 Category 2.
UL: UL recognized component per UL583 (pending).
Note: Regulatory compliance of the complete vehicle system with the controller
installed is the responsibility of the vehicle OEM.
