TP-6833 2/1610 Section 1 Product Description
1.3 Model Designation
Model Controls Voltage Poles Enclosure Current Rating ConnectionsMechanism Transition
Record the transfer switch model designation in the boxes. The transfer switch model designation defin es
characteristics and ratings as explained below.
Sample Model Designation: KCS-DNTA-0400S
Model
K: Kohler
Mechanism
C: Standard (Any Breaker)
Transition
S: Standard
P: Programmed
C: Closed
Controller
A:
Decision-Makerr MPAC 1200, Automatic
B:
Decision-Makerr MPAC 1200, Non-Automatic
D:
Decision-Makerr MPAC 1500, Automatic
F:
Decision-Makerr MPAC 1500, Non-Automatic
* Non-automatic controls are available on Models KCS and KCP
only.
Voltage/Frequency
C: 208 V o lts/60 Hz K: 440 Volts /60 Hz
D: 220 Volts /50 Hz M: 480 Volts /60 Hz
F: 240 V o lts/60 Hz N: 600 Volts / 60 Hz
G: 380 Volts/ 50 Hz P: 380 Volts /60 Hz
H: 400 Vo lts/50 Hz R: 220 Volts / 60 Hz
J: 416 Volts /50 Hz
Number of Poles/Wires
N: 2 Poles / 3 Wires, Solid Neutral
T: 3 Poles/ 4 Wires, Solid Neutral
V: 4 Poles/ 4 Wires, Switched Neutral
W: 4 Poles / 4 Wires, Overlapping Neutral
Enclosure
A: NEMA 1 D: NEMA 4
B: NEMA 12 F: NEMA 4X
C: NEMA 3R G: Open Unit
Current, Amps
0030 0260 1600
0070 0400 2000
0104 0600 2600
0150 0800 3000
0200 1000 4000
0230 1200
Connections
S: Standard
F: Front (1600 and 2000 amp only)
Note: Some selections are not available for every model.
Contact your Kohler distributor for availability.
