INFORMATION ABOUT USE
4
23
EN
Internal Communication: For internal & partner use only.
4 INFORMATION ABOUT USE
4.1 Pre-start check
• Read carefully the following pages and carry out the operations described below in accordance with the
instructions specified.
Important
• Non compliance with the operations described in the following pages involves the risk of damages to the
engine and vehicle on which it is installed as well as personal and/or property damage.
• Increase the frequency of maintenance operations in heavy working conditions (engine starts but stops, very
dusty and hot environments, etc..).
4.2 Break-in running
NOTE: For the first 50 hours of engine operation, it is advisable not to exceed 75% of the maximum power supplied.
4.3 Starting and turning off
1.
Check the level of the engine oil, fuel and coolant and fill if necessary (Par. 4.5 e Par. 4.6).
2.
Put the ignition key in the ignition switch (if supplied).
3.
Tun the key to ON position.
4.
Turn the key beyond the ON position and release it when the engine starts (the key will return into ON
position automatically).
Important
•
At the first fuelling or if the tank was empty filling the fuel system (Par 6.4 from point 4 to point 6)
•
Do not actuate the starter for more than 15 seconds at a time. If the engine does not start, wait for one
minute before repeating attempt.
•
If engine does not start after two attempts see Tab. 7.1 and Tab. 7.2 to found the cause.
Panel
L
can be assembled on the engine or machine. In
Tab. 4.1
are
described the main functions are illustrated.
Tab. 4.1
Control switch to start the engine
Warning Light - battery not charging
Warning Light - engine oil not pressurised
Warning Light - high coolant temperature
Warning Light - alarm general indicator
