INFORMATION ABOUT REPLACEMENTS
6
37
EN
Internal Communication: For internal & partner use only.
6.2 Oil filter cartridge replacement
Important
•
Before proceeding with operation, read Par. 3.2.2
Warning
•
In case of low use replace it 12 months.
•
For disposal of oil filter cartridge refer to Par. 6.6 DISPOSAL
and SCRAPPING.
1.
Unscrew the oil filter A with appropriate wrench.
Fig 6.5
2.
Assembly and tighten the new oil filter cartridge
A
tightening it
with torque wrench
B
(torque to
15 Nm
).
Fig 6.6
NOTE : Click on the icon to play the procedure.
https://youtu.be/v9pGAnWFd08
6.3 Remote oil filter cartridge replacement (optional)
Important
•
Before proceeding with operation, read Par. 3.2.2.
1.
Unscrew and remove the cartridge A using the appropriate
wrench.
2.
Lubricate the gasket and screw on the new cartridge A using
the appropriate wrench.
Fig 6.7
